681XZZ Miniature Ball Bearings 1.5x4x2mm Fingerboard Wheels Bearings ABEC-7 Micro bearing L-415ZZ
Ⅰ. About Miniature ball bearing:
681XZZ Miniature Ball Bearings 1.5x4x2mm Fingerboard Wheels Bearings ABEC-7 Micro bearing L-415ZZ
Product : 681xzz Fingerboard Ball Bearing
Size of The Bearing : - METRIC: 1.5mm (Inner) x 4mm (Outer) x 2mm (Height)
Material : GCr15 Chrome steel
Precision: ABEC-7 high precision
THIN-WALL BEARINGS WITH EQUAL SECTIONS
Equal section thin wall bearing has the features of low friction torque, high rigidity and good rotation precision. The steel ball adopts a small outer diameter and extremely thin cross section.
Silurian thin wall bearings with equal sections are divided into three types: deep groove ball bearings, angular contact ball bearings and four-point contact ball bearings. The inner, outer ring and rolling elements of equal section bearings are made of high carbon chromium bearing steel GCr15 while the cage is made of phenolic resin and nylon material.
Silurian offers three-dimensional thin-walled bearings of the metric size series of 8mmx8mm, 13mmx13mm, 20mmx20mm, with an inner diameter range of 25-360mm and an outer diameter range of 65-400mm.
Silurian provides equal section thin wall bearings with metric dimensions of 8mmx8mm, 13mmx13mm and 20mmx20mm and with inner diameter range of 25-360mm and outer diameter range of 65-400mm.
Silurian can also customize the inch series and non-standard series bearings for customers.
| New model | specification(mm) | Weight(kg) |
| dxDxB |
| 6900-2RS | 10*22*6 | - |
| 6901-2RS | 12*24*6 | 0.01 |
| 6902-2RS | 15*28*7 | 0.015 |
| 6903-2RS | 17*30*7 | 0.018 |
| 6904-2RS | 20*37*9 | 0.037 |
| 6905-2RS | 25*42*9 | 0.042 |
| 6906-2RS | 30*47*9 | 0.05 |
| 6907-2RS | 35*55*10 | 0.075 |
| 6908-2RS | 40*62*12 | 0.112 |
| 6909-2RS | 45*68*12 | 0.126 |
Ⅱ. Feature : high precision bearings have less internal friction and can work with smaller starting torque, which means a lower power consumption.
Ⅲ. Application: household appliances, dental drill, toys, electric power tools, electric motors, machine tools, measuring instruments, office machinery, Robot joint, facial beauty rollers, drone etc.
Ⅳ. Specification
- A deep groove ball bearings is the must popular type of rolling-element bearing composed of an outer race ball, an inner race and a bearing cage.and the race dimensions are close to balls dimensions.
- The materials for producing ball bearing are variety including stainless steel,chrome steel and silicon nitride and more with a simpler construction comparing with other ball bearing, deep groove bearings are suitable for large quantity production
- The function of deep groove ball bearings is to reduce rotation friction.those balls between outer race and inner race help avoid two flat surfaces rotating on each other thus to achieve the purpose of lowering down friction coefficient
- Additionally, deep groove ball bearings are primarily used to support radial loads; supports both radial and axial loads is also possible
- Deep groove ball bearings can be used in wide range of applications.
- Firstly, they can de used in industrial transmission mechanical products.
- Miniature bearings are widely used in household appliances, toys, electric power tools, car motors and other fields. With optimal design, high reliability heat treatment, precision manufacturing processes and high-grade grease, these products perform better on reliability, vibration and noise levels than standard products making them more suitable for electric motor applications. These products can also be applied to most gearbox applications as well.
- Thirdly, our bearing are ideal for electrical motor with good quality and excellent performance. Because of their high precision, high rotating speed, high reliability, low friction and low noise, they are widely used in areas of machine tools, measuring instruments, office machinery, household appliances, various types of electric motors, industrial automation control, etc.
Ⅴ. PACKING / Shipping
Transportation:
1. Less than 45 KGS, we will send by express. (Door to Door, Convenient)
2. Between 45 - 200 KGS, we will send by air transport. (Fastest and safest, but expensive )
3. More than 200 KGS, we will send by sea. (Cheapest and usual)
Payment:
1. TT. 30% payment in advance as deposit, balance before delivery.
2. L/C at sight. (high bank charges, not suggest , but acceptable )
3. 100% Western Union in advance. (specially for air shipment or small amount)
Package:
1. Neutral Packing
Bearing + Neutral Plastic Bag(Tube) or Neutral Box + Neutral Carton + Pallet;
2. Industrial Packing
Bearing + Industrial Kraft Paper + Carton + Pallet;
3. Commercial Packing
Bearing + Plastic Bag + Color Box + Carton + Pallet;
4. As Your Requirement.
Q: Are you trading company or manufacturer?
A: We are factory. Dongguan Youchi Bearing Co.,Ltd integrates production, trade, investment and sales.
Q: How long is your delivery time?
A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods out of stock, depends on order quantity.
Q: Do you provide samples ? is it free or extra?
A: Yes, we could provide free samples, but freight collect.
Q: What is your terms of payment ?
A: Payment<=2,000USD, 100% in advance. Payment>2,000USD, 30% T/T in advance, balance before shipment.
Welcome to contact us if any interested. Thanks~
Product Tags:
|
|
681XZZ 1.5x4x2mm Fingerboard Wheel Bearings ABEC-7 L-415ZZ Images
|
